Highlights
- Ideal solution for starting to use the MAX! system: In the MAX! Radiator solution immediately ready for use to control single radiators - even without Internet connection
- Can be individually tailored to personal routines thanks to the freely programmable heating phases (13 switching times per day for temperature switch-over) directly on the radiator thermostat
- Simple expansion to MAX! Room or House solution
- Easy installation without having to intervene in the heating system; no special tools required
- Ready to use straight away thanks to pre-set week programs
- Precise temperature adjustment (to the nearest 0.5°C)
- Automatic temperature reduction when the windows are opened for ventilation and adjustment of the temperature when they are closed in connection with MAX! Window Sensors
- Frost protection function automatically opens valves if necessary
- Limescale protection automatically protects against calcification thanks to regular opening and closing of the valves
- Boost button for heating up the radiator immediately
- Tamper-proof thanks to child-proof lock/operating lock
- Theft protection available as an option
Technical Specifications
Supply voltage
2x 1.5 V LR6/mignon/AA
Current consumption
100 mA max.
Battery life
2 years (typ.)
Display
LC display (backlit)
Threaded connection
M30 x 1.5 mm
Dimensions (W x H x D)
60 x 65 x 100 mm
Weight
216 g (incl. batteries)
Radio frequency
868,3 MHz
Typ. open area RF range
> 100 m
Ordering Informations
Product Name
BC-RT-TRX-CyG-4
Item Number
105936
EAN Code
4047976059362
Package
45
Dimesions incl. Packaging
122 x 112 x 97 mm
Weight incl. Packaging
372,0 g
