HomeMatic Wireless Temperature Sensor, outdoor

Wireless Temperature Sensor with remote sensor for temperature measurement

HomeMatic Wireless Temperature Sensor, outdoor HomeMatic Wireless Temperature Sensor, outdoor HomeMatic Wireless Temperature Sensor, outdoor HomeMatic Wireless Temperature Sensor, outdoor HomeMatic Wireless Temperature Sensor, outdoor
HomeMatic Wireless Temperature Sensor, outdoor
HomeMatic Wireless Temperature Sensor, outdoor
HomeMatic Wireless Temperature Sensor, outdoor
HomeMatic Wireless Temperature Sensor, outdoor
HomeMatic Wireless Temperature Sensor, outdoor
Highlights
  • Suitable for measuring temperature within a range of -19.9 to +79.9 °C
  • Ideal for use in outdoor areas (IP65)
  • Measured values are transmitted cyclically to the Homematic Central Control Unit or other Homematic devices
  • Sensor cable length of 3 m
Technical Specifications
Supply voltage
2x 1.5 V LR03/micro/AAA
Battery life
2.5 years (typ.)
Degree of protection
IP65
Temperature range
-19.9 to +79.9 °C
Accuracy
±1°C
Housing
ABS
Dimensions (W x H x D)
63 x 58 x 35 cm
Weight
95 g (not incl. batteries)
Radio frequency
868.3 MHz
Typ. open area RF range
300 m
Ordering Informations
Product Name
HM-WDS30-T-O
Item Number
76922
EAN Code
4047976769223
Package
90
Dimesions incl. Packaging
122 × 112 × 48 mm
Weight incl. Packaging
182,0 g
Downloads
Manual
Product Data Sheet
Declaration of conformity
