HomeMatic Wireless Radiator Thermostat

Enables time-controlled regulation of the room temperature and individual adjustment of heating phases according to your personal needs

HomeMatic Wireless Radiator Thermostat HomeMatic Wireless Radiator Thermostat HomeMatic Wireless Radiator Thermostat HomeMatic Wireless Radiator Thermostat HomeMatic Wireless Radiator Thermostat HomeMatic Wireless Radiator Thermostat
HomeMatic Wireless Radiator Thermostat
HomeMatic Wireless Radiator Thermostat
HomeMatic Wireless Radiator Thermostat
HomeMatic Wireless Radiator Thermostat
HomeMatic Wireless Radiator Thermostat
HomeMatic Wireless Radiator Thermostat
Highlights
  • Flexible due to pre-set week programmes and individual configuration directly on the device
  • Can be individually tailored to personal routines thanks to the freely programmable heating phases (13 switching times per day for temperature switchover)
  • Temperature can be automatically reduced during ventilation using integrated open window detection or window contact that can be connected
  • Compatible with valves of most manufacturers and easy to mount
  • Boost function for heating up the radiator quickly and briefly
  • Precise temperature adjustment (to the nearest 0.5°C)
  • Automatic frost protection automatically opens valves if necessary
  • Automatic limescale protection: automatic protection against calcification thanks to regular opening and closing of the valves
  • Firm connection thanks to metal knurled nut
  • New room concept enables easy set-up with CCU2



Technical Specifications
Supply voltage
3 V
Batteries
2x 1.5 LR6/Mignon/AA
Battery life
1.5 years (typ.)
Current consumption
180 mA (max.)
Degree of protection
IP20
Protection class
III
Ambient temperature
0 to 55°C
Weight
180 g (not incl. batteries)
Dimensions (W x H x D)
54 x 65 x 93 mm
Radio frequency
868.3 MHz
Receiver category
SRD Class 2
Typ. open area RF range
300 m
Duty Cycle
< 1% per h
Valve connection
M30 x 1.5
Ordering Informations
Product Name
HM-CC-RT-DN
Item Number
105155
EAN Code
4047976051557
Package
60
Dimesions incl. Packaging
122 x 112 x 73 mm
Weight incl. Packaging
368,0 g
Downloads
Manual
Product Data Sheet
Declaration of conformity
