Highlights
- Wireless switch actuator with power metering combines two functionalities in one device:
1. Switching connected devices (switching channel)
2. Metering voltage, current consumption, active power, frequency and energy consumption (metering channel) - With the "conditional switching function", connected loads or Homematic devices can be switched independently via the CCU2 WebUI according to individually defined metering values
- Measured data such as voltage, current consumption, active power, frequency and energy consumption up to 3680 W/16 A can be send cyclically and event-related to the Homematic CCU2
- Display of metered data via the WebUI user interface
- Rugged design: cosφ=1: 50,000 switching cycles
Technical Specifications
Supply voltage
230 V/50 Hz
Current consumption
14 A max. (16 A for 30 min.)
Power consumption in standby
< 0.6 W
Ambient temperature
-10 to +35 °C
Radio frequency
868.3 MHz
Typ. open area RF range
300 m
Measurement category
CAT II
Max. switching capacity
3220 W permanent (3680 W for 30 min)
Load type
ohmic load
Relay
NO Contact, 1-pole, μ contact
Dimensions (W x H x D)
59 x 122 x 40 mm (not incl. mains plug)
Weight
179 g
Ordering Informations
Product Name
HM-ES-PMSw1-Pl-DN-R1
Item Number
130248A0
EAN Code
4047976302482
Package
32
Dimesions incl. Packaging
184 x 140 x 73 mm
Weight incl. Packaging
356,0 g
