Highlights
- Display of user-defined states with integrated multi-colour signal lamp
- Implementation of various functionalities is possible in connection with other Homematic devices and the Homematic WebUI
- The device can be used e.g. as doorbell or alarm signal if windows or doors are opened
- Individual MP3 files can be added to default sound clips (using a microSD/SDHC card)
- Easy to mount on walls or flexible use as standing unit
Technical Specifications
Supply voltage
2x 1.5 V LR14/baby/C
Battery life
2 years (typ.)
Power consumption in standby
max. 0.15 mA
Degree of protection
IP20
File formats supported
MP3 (CBR, VBR, ABR)
Bit rates supported
32 / 320 Kbit/s
Memory cards supported
FAT32 file system formatted microSD/microSDHC memory card, storage capacity up to 16 GB, performance up to class 10 with a max. number of 254 tracks
Dimensions (W x H x D)
60 x 155 x 69 mm
Weight
180 g (incl. batteries)
Radio frequency band
868.0-868.6 MHz
Typ. open area RF range
120 m
Ordering Informations
Product Name
HM-OU-CFM-TW
Item Number
142873A0
EAN Code
4047976428731
Package
32
Dimesions incl. Packaging
184 x 140 x 73 mm
Weight incl. Packaging
564,6 g
