Radiator Thermostat Model M

Enables time-controlled regulation of room temperature for comfort and savings

Radiator Thermostat Model M Radiator Thermostat Model M Radiator Thermostat Model M Radiator Thermostat Model M Radiator Thermostat Model M Radiator Thermostat Model M
Radiator Thermostat Model M
Radiator Thermostat Model M
Radiator Thermostat Model M
Radiator Thermostat Model M
Radiator Thermostat Model M
Radiator Thermostat Model M
Highlights
  • Suitable for universal use; compatible with products of most popular thermostatic valve manufacturers
  • Easy to mount, no special tools required, no water draining, no intervention to heating control system
  • Easy operation thanks to inclined arrangement of buttons and display
  • Ready to use due to pre-set programming
  • Self-programmable to meet personal routine - up to 3 heating phases (7 change settings) can be set separately for day, weekday, weekend, or whole week
  • Temperature can be set to nearest 0.5° or changed intuitively via control wheel
  • Boost function to increase radiator heat for up to 5 minutes
  • Rapid temperature fall / room ventilation detection
  • Holiday Function
  • Automatic frost protection
  • Temperature offset function to adapt for room / radiator variance
  • Operational “lock” for tamper / child resistant controls
  • Valve protection function: Weekly automatic de-calcification
  • Timeless, plain housing and compact design
  • Low-noise gearbox
Technical Specifications
Supply voltage
2x 1.5 V LR6/Mignon/AA
Current consumption
100 mA max.
Battery life
3 years (typ.) - 3 heating cycles
Display
LCD
Degree of protection
IP20
Threaded connection
M30 x 1.5 mm
Dimensions (W x H x D)
58 x 63 x 122 mm
Weight
176 g (incl. batteries)
Ordering Informations
Product Name
CC-RT-M
Item Number
141227
EAN Code
4047976412273
Package
60
Dimesions incl. Packaging
122 x 112 x 73 mm
Weight incl. Packaging
267,6 g
Downloads
Manual
Product Data Sheet
Declaration of conformity
