Highlights
- Comfort throughout the entire room at the touch of a button: Central control and comfortable setup of a MAX! Room solution with up to 8 MAX! Radiator Thermostats and 8 MAX! Window Sensor - no PC or Internet connection required
- Local programming of comfort and reduction temperature
- Configuration in the MAX! House solution via the MAX! software
- An internal sensor precisely measures the temperature in a room and cyclically transmits it to the radiator thermostats
- Boost button for heating up all the radiators in the room instantly
- Large, easy-to-read display (LCD)
- Room/setpoint temperature permanently displayed
- Switch between automatic and manual operation
- Integrated holiday function for adaptation of room temperature during longer absence
- Wall mounting with supplied clip-on frame or integration into existing switches from the following manufacturers: Berker (S.1, B.1, B.3, B.7 Glas), GIRA (System 55, Standard 55, E2, E22, Event, Esprit), Merten (1-M, Atelier-M, M-Smart, M-Arc, M-Star, M-Plan) und JUNG (A 500, AS 500, A plus, A creation), ELSO (Joy)
Technical Specifications
Supply voltage
2x 1.5 V LR03/micro/AAA batteries
Current consumption
30 mA max.
Batterie life
2 years (typ.)
Display
LCD
Degree of protection
IP20
Dimensions (W x H x D)
86 x 86 x 21.5 mm
Ambient temperature
5 to 50 °C
Weight
101 g (incl. battery)
Radio frequency
868.3 MHz
Typ. open area RF range
> 100 m
Ordering Informations
Product Name
BC-TC-C-WM-4
Item Number
131651A0B
EAN Code
4047976316519
Package
90
Dimesions incl. Packaging
122 x 112 x 48 mm
Weight incl. Packaging
184,4 g
