Highlights
-
Enables switching of devices that work with batteries and rechargeable batteries as well as magnetic valves - suitable for camping and caravanning
-
Long-life batteries and rechargeable batteries offer long-life operation
-
Secure bidirectional radio connection
-
Operation via different Homematic devices (e.g. wireless push-button or remote control) as well as via the WebUI user interface
-
Connecting cables with up to 3 m length
Technical Specifications
Supply voltage
Battery operation, 5-15 VDC
Average current consumption
100 μA
Current consumption
21 mA max.
Output
Open drain output 20 V/3 A
Operating temperature
0 to 50 °C
Radio frequency
868.3 MHz
Typ. open area RF range
100 m
Dimensions (W x H x D)
45 x 24 x 45 mm
Weight
13.8 g
Length of connection power
3 m max.
Ordering Informations
Product Name
HM-LC-Sw1-Ba-PCB
Item Number
104895
EAN Code
4047976048953
Package
144
Dimesions incl. Packaging
122 x 93 x 36 mm
Weight incl. Packaging
68,9 g
