Highlights
- Switches up to 4 connected loads
- For independent switching of components without an RS485 connection or an external antenna
- 4 inputs/outputs
- Can be configured and controlled wirelessly via the Homematic Central Control Unit CCU2
- Loads of up to 3680 W power consumption can be connected
- DIN-rail housing with width of 4 WM
- Device is equipped with operation/configuration button and display
- Low energy consumption
Technical Specifications
Supply voltage
230 V/50 Hz
Current consumption
20 mA
Power consumption in standby
0.25 W
Maximum switching capacity
3680 W (230 V/50 Hz/16 A per channel, total for all channels 25 A/5750 W max.)
Degree of protection
IP20
Dimensions (W x H x D)
72 x 65 x 87 mm (standard DIN-rail housing with 4 WM width)
Weight
189 g
Radio frequency
868.3 MHz
Typ. open area RF range
150 m
Ordering Informations
Product Name
HM-LC-Sw4-DR-2
Item Number
132763A0
EAN Code
4047976327638
Package
60
Dimesions incl. Packaging
122 x 112 x 73 mm
Weight incl. Packaging
269,0 g
